GWT-77A Engine Water Pump Fits Toyota Camry/Vista SV40 SV41 SV42 SV43

Product Description

Product Function Description

The engine water pump is a critical component of your Toyota Camry or Vista‘s cooling system. Its primary function is to circulate coolant through the engine block, cylinder head, and radiator, dissipating the intense heat generated by the combustion process. For Toyota SV40, SV41, SV42, and SV43 models (1992-2001), a properly functioning water pump is essential for maintaining optimal engine temperature, preventing overheating, and protecting engine components from thermal damage . This water pump is manufactured to factory specifications, ensuring a perfect fit and reliable cooling system operation. It features a cast iron impeller and high-quality bearing for long-lasting performance .

When Should You Replace It?

Consider replacing your water pump if you experience any of the following symptoms:

• Coolant leaks visible around the water pump area or under the vehicle

• Engine overheating – the temperature gauge reads higher than normal

• Whining, grinding, or rattling noise from the water pump area

• Low coolant level without visible external leaks elsewhere

• Steam or coolant smell coming from the engine compartment

• The vehicle‘s heater is not blowing hot air (may indicate low coolant flow)

• The water pump pulley is loose or wobbling

• Engine temperature fluctuates unexpectedly during driving

• Dashboard warning light related to engine temperature illuminates

Note: Water pumps are wear items that should be inspected regularly and replaced when signs of failure appear. For these models, the water pump is driven by the timing belt and should be replaced as part of timing belt service .

Product Specifications

Why Choose This Water Pump?

Factory Specification Quality – This water pump is manufactured to the exact standards of the original cooling system component, ensuring proper fit and reliable coolant circulation performance for your Camry or Vista.

Restores Cooling System Function – A failing water pump causes overheating and engine damage. This new pump restores proper coolant flow, keeping your engine at optimal operating temperature for reliable performance and fuel efficiency.

Built for Long Service Life – Constructed with a cast iron impeller and high-quality bearing, this pump is designed to withstand the demands of daily driving and provide long-lasting durability .

Prevents Costly Engine Damage – Overheating from a failed water pump can cause warped cylinder heads, blown head gaskets, and severe engine damage. Replacing a failing pump early is cost-effective protection.

Direct Replacement – Precision-engineered to match the original water pump specifications. Direct bolt-on replacement – no modifications required.

Designed for Your Engine – This pump is specifically designed for the 3S-FE, 4S-FE, and 5S-FE engines used in the SV40-43 chassis, ensuring correct fitment and performance .

Essential When Replacing Timing Belt – Since the water pump is driven by the timing belt on these engines, replacing it at the same time as the timing belt is recommended to avoid future labor costs .

Package Contents

1 x Engine Water Pump with Gasket. Note: Coolant and mounting bolts are NOT included – please purchase separately. This pump is compatible with 3S-FE, 4S-FE, and 5S-FE engines. Please confirm compatibility with your Toyota model and year before purchasing. It is recommended to replace the water pump at the same time as the timing belt .

Installation Tips

Important: Allow the engine to cool completely before installation. Drain the cooling system and properly dispose of old coolant. Remove the timing belt to access the water pump . Clean the mounting surface thoroughly – remove all old gasket material and residue. Install the new water pump with the provided gasket. Tighten the mounting bolts to factory torque specifications. Reinstall the timing belt, ensuring correct timing alignment. Reconnect all coolant hoses and fill the cooling system with fresh Toyota-approved coolant (50/50 mixture of coolant and distilled water). Start the engine and allow it to reach operating temperature. Check for coolant leaks around the pump area. Bleed the cooling system to remove trapped air. Recheck coolant level after the engine cools. Professional installation is recommended if you are not familiar with timing belt and cooling system repairs.

Inspection & Maintenance Recommendations

The water pump is a wear item that can fail due to bearing wear, seal leakage, or impeller damage. Regular inspection is recommended to prevent engine overheating.

Common indicators that the water pump may need replacement:

Inspection Checklist:

• Inspect the water pump area for signs of coolant leaks or residue.

• Check for play in the water pump pulley by attempting to move it (engine off).

• Look for rust or corrosion around the pump housing.

Maintenance Tips:

• Replace the water pump when performing a timing belt service (typically every 60,000–100,000 miles).

• Always replace the water pump gasket or O-ring when installing a new pump to prevent leaks.

Quality Assurance & Service Commitment

Quality Assurance:
Every component is manufactured under controlled production processes to ensure consistent dimensional accuracy and material integrity. Each unit undergoes the following quality checks before packaging:

• Dimensional inspection – critical mounting points are verified against design specifications

• Impeller integrity check – ensures proper construction and balance

• Surface finish inspection – corrosion protection and surface quality are visually verified

Packaging Protection:
Each water pump is individually sealed in protective packaging to prevent contamination and physical damage during storage and transit. The packaging includes a clear part number label for easy identification.

Service Commitment:

Related Product Recommendations

When replacing the water pump, it is often recommended to inspect and consider replacing the following related components at the same time.

Recommended Related Parts:
